About MS Waller Plate

Waller Plate Formwork Details

A Waller Plate is a steel plate used in shuttering/formwork systems to distribute the load from a tie rod and wing/anchor nut over the formwork waler. It helps prevent local deformation of the shuttering panel and provides a firm connection.

Specification	Typical Details
Product	Waller Plate
Application	MS/Steel formwork & shuttering
Material	Mild Steel / Cast or Forged Steel
Shape	Square / Rectangular plate
Typical Thickness	612 mm
Common Size	Approx. 120 120 mm to 150 150 mm
Hole	Central hole for tie rod
Finish	Black / Painted / Galvanized
Used With	Tie Rod + Wing Nut / Anchor Nut
Purpose	Load distribution & securing formwork

Suggested quotation description

WALLER PLATE HEAVY-DUTY MS/STEEL PLATE WITH CENTRAL HOLE, USED WITH FORMWORK TIE ROD AND NUT ASSEMBLY FOR SECURING SHUTTERING PANELS AND DISTRIBUTING TIE-ROD LOAD OVER THE Waler.

Typical example:
Waller Plate 150 150 10 mm, MS, central hole suitable for 16 mm tie rod.
